400mm Probe Shaft Testo 405I Smart Probe Testo405I Thermal Anemometer with Smartphone Operation

400mm Probe Shaft Testo 405I Smart Probe Testo405I Thermal Anemometer with Smartphone Operation

400mm probe shaft Testo 405i Smart Probe Testo405i Thermal anemometer with smartphone operation Product Feature: With th

Send your inquiry

DESCRIPTION

Basic Info.
Model NO. Testo 405i
Shakeproof Shakeproof
Noctilucence Without Noctilucence
Waterproof Not Waterproof
Weight >100g
Operating Temperature 0.1 °c
Dimensions 183 X 90 X 30 mm
Battery Life 15 H
Storage Temperature -20 to +60 °c
Length Probe Shaft 400 mm
Order Numer 0560 1405
Product Name Thermal Anemometer
Model Number Testo 405I
Measuring Range -20 ~ +60 °c
Resolution ±0.5 °c
Transport Package One Piece/Box
Specification 200 x 30 x 41 mm
Trademark Testo
Origin Germany
HS Code 9025191000
Production Capacity 10000PCS/Year
Product Description
400mm probe shaft Testo 405i Smart Probe Testo405i Thermal anemometer with smartphone operation

Product Feature:

  • for measuring volume flow, air velocity and temperature

  • Simple configuration of the dimension and geometry of the duct cross-section for determining the volume flow

  • Convenient for working in ventilation ducts thanks to its telescopic tube, which can be extended up to 400 mm

  • Really convenient to operate thanks to the testo Smart Probes App (e.g. easy viewing of readings, measurement data trend, log function)

With the testo 405i hot wire anemometer, you can measure air velocities, temperatures and volume flows. Via Bluetooth, the readings are transmitted wirelessly straight to the testo Smart Probes App on your smartphone or tablet. You can view the values conveniently and use numerous intelligent features

Product Description

  • No more surprises: the testo 405i thermal anemometer with smartphone operation from the Testo Smart Probes series is ideal for carrying out measuring tasks in ventilation ducts. It is easy to use the anemometer to determine air velocity, temperature and volume flows. The testo 405i is also suitable for measuring indoor air velocity. Practical when, for example, you want to locate non-airtight windows. Cooling capacities and heating outputs can also be calculated when used in conjunction with the testo 605i thermohygrometer.
  • Operation independent of measuring location via your smartphone

    The testo 405i hot wire anemometer combines professional Testo measuring technology with App-based operation. This means you benefit from numerous additional functions in your day-to-day work. With the testo Smart Probes App, you can view readings conveniently on your smartphone or tablet. You no longer have to spend ages trying to make out the display at poorly accessible points. Volume flow can also be measured easily using the App: following intuitive input of the duct cross-section, the App calculates this completely automatically.The App opens up other practical options too: it not only displays measurement data, but also evaluates and documents it. It is easy to carry out a timed and multi-point mean calculation with the App. It also displays the measurement data curve at the press of a button. And sends the measurement data logs as PDF or Excel files.System requirements:

  • iOS 8.3 or later
  • Android 4.3 or later
  • Bluetooth 4.0
  • Delivery Scope

    testo 405i thermal anemometer with smartphone operation, including extendible (400 mm) telescope, batteries and calibration protocol.


Techincal Data:
Temperature - NTC

Measuring range

-20 to +60 °C

Accuracy

±0.5 °C

Resolution

0.1 °C

Velocity - Hot wire

Measuring range

0 to 30 m/s

Accuracy

±(0.1 m/s + 5 % of mv) (0 to 2 m/s)

±(0.3 m/s + 5 % of mv) (2 to 15 m/s)

Resolution

0.01 m/s

General technical data

Dimensions

200 x 30 x 41 mm

Operating temperature

-20 to +50 °C

System requirements

requires iOS 8.3 or newer; requires Android 4.3 or newer; requires mobile end device with Bluetooth 4.0

Battery type

3 AAA micro batteries

Battery life

15 h

Length probe shaft

400 mm

Storage temperature

-20 to +60 °C

General technical data

Dimensions

183 x 90 x 30 mm

Operating temperature

-20 to +50 °C

System requirements

requires iOS 8.3 or newer; requires Android 4.3 or newer; requires mobile end device with Bluetooth 4.0

Battery type

3 AAA micro batteries

Battery life

150 h

Storage temperature

-20 to +60 °C
