DESCRIPTION

Basic Info.

Model NO.	TXFS
Shakeproof	Shakeproof
Noctilucence	Without Noctilucence
Waterproof	Waterproof
Weight	>100g
Place of Origin	Shanghai, China (Mainland)
Working Voltage	24V
Model Number	Txfs-2/ Txfs-3
Material	Plastic,Aluminium
Transport Package	Carton
Specification	SGS
Trademark	STRONG
Origin	Shanghai
HS Code	84313900
Production Capacity	20000PCS/Year

Product Description

1)Product description

TXFS-2 anemometer is used for buildings, meteorological
stations (stations), chemical industry, power plants, industrial enterprises and
other units to record air travel and instantaneous wind
speed and wind observation devices. Can be implemented using TXFS-2-
type microcomputer intelligent digital anemometer wind
speed indicates the digitizationand automation of equipment, it is indispensable to mo
dern equipment, related equipment.
TXFS-2 digital anemometer is made
up of intelligent microcomputer Intelligent measuring and
control instruments, windspeed sensor is composed of two parts. Intelligentinstrument
case with metal shell, durable, boards adopt and import the ATMEL chip and thecorr
esponding external circuit, display using a single window to highlight four groups of1
2-digit NIXIE tube display, extensive use of advanced foreign technology. TXFS-2-
typemicrocomputer intelligent digital marine anemometer wind
speed detecting sensor of measuring wind speed sensor, ship, TXFS-
2 compared with traditional products microcomputerintelligent digital anemometer, w
ith high precision and wide range of application,convenient data logger, good quality,
stable and reliable.
2)Technical parameters

Display data	Wind speed and wind scale two-row display
Power	DC12V ±10%
Insulation capability	≥10MΩ
Dimensions	165mm*105mm*49mm
Power consumption	≤15W
Wind alarm setting	Set alarm wind scale can be arbitrary

3)Product features

F1. Board chips plus core adopt imported ATMEL company independently developed
microcontroller Board and supporting the standard I/O cards, plus the corresponding s
ignalconditioning modules, data
acquisition and output flexibility to change control andreliability further improved;
F2. Low-power digital circuits using ATMEL company chips;
F3. Power off memory function, you can continuously work;
F4. Hardware has a WATCHDOG circuit, the software also has strong anti-
jamming function;
F5. Installation and commissioning of all buttons, user adjustment is very convenient;
F6. With sound and light alarm function;
F7. the host machine adopts metal housing, durable, cups made of aluminum
alloy material,robust and reliable.
1. wind speed indicator (1) wind speed measurement range: 0~56m/s, 0~16-level (2) accuracy of <56m/s ± (0.5+0.05v) ≥56m/s±5% (3) start wind speed wind speed sensor: <0.7m/s (4) to display parameter: the actual wind speed alarm, wind, wind, wind maximum winds 2. alarm limit value (meter factory setting): lifting status (level 4), work status (level8), limit value can be adjusted according to customer requirements (can be selected) 3.0~800HZ pulse output (0~56m/s) 4. working environment temperature: Host:-30 ° C~65 ° c Sensors:-30 ° C~65 ° c
